对色灯管规格型号有哪些？我们该如何查看呢？由于对色灯光的使用寿命相对于普通日光灯来说更短，所以其更换也会较为频繁，所以搞清楚对色灯光的规格型号是十分有必要的。
对色灯管规格型号有哪些？我们该如何查看呢？由于对色灯光的使用寿命相对于普通日光灯来说更短，所以其更换也会较为频繁，所以搞清楚对色灯光的规格型号是十分有必要的。
对色灯管有哪些？
对色灯广泛应用于纺织，印染，塑胶，油漆，油墨，印刷，颜料，化工，陶瓷，鞋业，皮革，五金，食品，化妆品各行各业的目测评定，配色打样，鉴别色差，荧光物质等颜色管理领域，使试样，生产，质检，验收在相同的标准光源下行，准确校对货品的颜色偏差，保证货品之颜色的品质符合要求。从而提高产品质量和市场竞争力，分为D65灯管，D50灯管，TL84灯管，TL83灯管，CWF灯管，U30灯管，U35灯管，UV灯管，HOR灯，F灯泡，A灯泡,产品符合国际标准化组织（ISO）在2000年对标准观察环境和标准光源做出了规定，即ISO3664:2000标准
怎么看对色灯管规格型号？
常用的是T8、T5、T4灯管，还有T10、T12。那么，这个“T”代表“Tube”，表示这个东西是管状的,T后面的数字表示灯管直径。
每一个“T”就是1/8英寸，一英寸等于25.4mm。那么每一个“T”就是
25.4÷8＝3.175mm，那么T8灯管的直径就是25.4mm。
T12灯管的直径就是(12/8)×25.4＝38.1mmT10灯管的直径就是(10/8)×25.4＝31.8mm
T8灯管的直径就是(8/8)×25.4＝25.4mm(T8的刚好是直径一英寸的灯管)
T5灯管的直径就是(5/8)×25.4＝16mm
T4灯管的直径就是(4/8)×25.4＝12.7mm其他灯管的管径尺寸依此类推：
T3.5直径11.1mm
T2直径6.4mm
长度与功率：
T8灯管的长度(注：统一宽度39mm、高度52mm）
20w长620mm;
30w长926mm;
40w长1230mm;
T5灯管的长度(注：统一宽度23.5mm、高度39mm）
8w长310mm;
14w长570mm;
21w长870.5mm;
28w长1170.5mm;
35w长1475mm;
T4灯管的长度(注：统一宽度21mm、高度32mm）
8w长341mm;
12w长443mm;
16w长487mm;
20w长534mm;
22w长734mm;
24w长874mm;
26w长1025mm;
28w长1172mm;
各种光源对色灯管种类大全：
D65
PHILIPS TLD18W/965 MADE IN HOLLAND 60cm
GRETAGMACBETH 6500K F20T12/65 MADE IN CANADA 60cm
VeriVide Artificial Daylight F20T12/D65 MADE IN E.E.C. 60cm
GE F20W/AD MADE IN HUNGARY 60cm 已停产
PHILIPS TLD36W/965 MADE IN HOLLAND 120cm
GE F40W/AD MADE IN HUNGARY 120cm 已停产
GRETAGMACBETH 6500K F40T12/65 MADE IN CANADA 120cm
VeriVide Artificial Daylight F40T12/D65 MADE IN EU 120cm
PHILIPS TLD58W/965 MADE IN HOLLAND 150cm
MACBETH SPL III 专用D65 750W 120V
SYLVANIA F20T12/D65 ARTIFICIAL DAYLIGHT MADE IN GERMANY 60cm
OARAM L18W/965 BIOLUX Recyclable Germany 60cm
OARAM L30W/965 BIOLUX Recyclable Germany 90cm
PHILIPS Graphica 18W/965 MADE IN HOLLAND 60cm
PHILIPS Graphica 58W/965 MADE IN HOLLAND 150cm
PHILIPS Graphica 36W/965 MADE IN HOLLAND 60cm
D75
GRETAGMACBETH 7500K F20T12/75 MADE IN CANADA 60cm
GE F40C75 30PK Made in USA
D50
PHILIPS TLD18W/950 MADE IN HOLLAND 60cm
GRETAGMACBETH 5000K F20T12/50 MADE IN U.S.A. 60cm
GRETAGMACBETH 5000K F40T12/50 MADE IN CANADA 120cm
PHILIPS TLD36W/950 MADE IN HOLLAND 120cm
PHILIPS TLD58W/950 MADE IN HOLLAND 150cm
PHILIPS Graphica 18W/950 MADE IN HOLLAND 60cm
PHILIPS Graphica 36W/950 MADE IN HOLLAND 120cm
PHILIPS Graphica 58W/950 MADE IN HOLLAND 150cm
TL84
PHILIPS TLD18W/840 MADE IN THAILAND 60cm
PHILIPS MASTER TLD18W/840 Made in Holland 60cm
PHILIPS MCFE 20W/840 P15 MADE IN POLAND 60cm Marks&Spencer指定
VeriVide F18T8/840P15 MADE IN EU 60cm
PHILIPS T20T12/41U U.S.A. 60cm
PHILIPS TLD30W/840 MADE IN THAILAND 90cm
PHILIPS TLD36W/840 MADE IN CHINA 120cm
PHILIPS TLD58W/840 MADE IN THAILAND 150cm
PHILIPS MCFE 40W/840 MADE IN POLAND 120cm Marks&Spencer指定
OSRAM L36W/840 LUMILUX Germany 120cm
TL83
PHILIPS TLD18W/830 MADE IN THAILAND 60cm
PHILIPS MASTER TLD18W/830 Made in Holland 60cm
PHILIPS MCFE 20W/830 MADE IN POLAND 60cm Marks&Spencer指定
PHILIPS TLD30W/830 MADE IN THAILAND 90cm
PHILIPS TLD36W/830 MADE IN CHINA 120cm
PHILIPS MCFE 40W/830 MADE IN POLAND 120cm Marks&Spencer指定
PHILIPS TLD58W/830 MADE IN THAILAND 150cm
CWF
PHILIPS TLD18W/33 Made in HOLLAND 60cm
GE F20W/33 MADE IN HUNGARY 60cm
SYLVANIA F20T12/CW CANADA 60cm
SYLVANIA F20T12/CW USA 60cm
SYLVANIA F20T12/33-640 MADE IN GERMANY 60cm
PHILIPS TLD36W/33-640 MADE IN CHINA 120cm
GE F30W/33 Made IN Gt.Britain 90cm
GE F40W/33 MADE IN HUNGARY 120cm
SYLVANIA F40T12/33-640 MADE IN GERMANY 120cm
UV
GE F20 BLB USA 60cm
PHILIPS TLD18W BLB MADE IN HOLLAND 60cm
SYLVANIA F18W/BLB-T8 CH 60cm
SYLVANIA F18W/BLB-T8 Made in Japan 60cm
SYLVANIA F30W/BLB-TB Made in Japan 90cm
GE F40 BLB USA 120cm
SYLVANIA F6W/BLB-T5 Made in Japan
U30
PHILIPS MASTER TLD18W/830 3000K 60cm
PHILIPS MASTER TLD36W/830 3000K 120cm
PHILIPS F20T12/30U 3000K U.S.A. 60cm
PHILIPS F30T12/30U/RS 3000K U.S.A. 90cm
U35
GE Ecolux F17T8 SPX35 ECO 3500K Made in Canada 60cm Target指定
GE Ecolux F20T12 SPX35 ECO USA 60cm Target指定
GE Ecolux F25T8 SPX35 ECO 3500K Made in Canada 90cm Target指定
GE Ecolux F32T8 SPX35 ECO 3500K Made in Canada 120cm Target指定
F灯
GE 40W 220V 螺口
PHILIPS 40W 220V 螺口 已停产，找代用型号
GE 40W 220V 卡口 VeriVide CAC60 专用
INCA A灯
inca 120V 75W Macbeth Judge II 专用
illuminant A 120V 150W Macbeth SPL III 专用
HalogenA 60W 230V 美式灯箱专用
Horizon(HOR)
SYLVANIA 120V 500W Macbeth SPL III专用
10000K
SYLVANIA AQUASTER F18W/174-T8 10000K MADE IN GERMANY 60cm
DNP灯管
DNP灯箱专用灯管 DNP灯管 FL10D-EDL-56K灯管
